Ceramic Fiber Tape

Heat resistant ceramic fiber insulation tape for pipe wrapping, cable protection, and high-temperature sealing.

Thickness: 2/3/5mm
Width: 25-150mm
Temperature: Up to 1260℃
Reinforcement: Fiberglass filament

Overview

✦ Flexible and easy to wrap
✦ Up to 1260℃ resistance
✦ Low thermal conductivity
✦ Good chemical stability

Woven textile from high-quality ceramic fiber yarn providing thermal insulation, fire resistance, and flexibility for wrapping pipes, cables, and irregular shapes.

What Is Ceramic Fiber Tape?

Ceramic fiber tape is a narrow woven flat tape made from ceramic-fibre yarn (often reinforced with fibreglass or stainless-steel wire), used for wrapping, gasketing and protective jacketing in high-temperature service.

Key Technical Specifications

Property	Value
Maximum service temperature	classification 1260°C; service up to 1100°C
Density	woven yarn basis; finished tape 2–6 mm thick
Thermal conductivity	0.08–0.15 W/(m·K) (as wrapped layer)
Standard thickness	2–6 mm
Standard dimensions	widths 10–100 mm; rolls 30 m typical
Fire classification	Non-combustible (ceramic fibre, asbestos-free)
Composition	high-purity alumino-silicate (Al₂O₃ + SiO₂) blown fibre, no organic binder
Standards	ASTM C892, ASTM C1086, ISO 10635, EN 10964

Properties & Advantages

Flexible, narrow-section high-temp seal
Withstands repeated thermal cycling
Optional wire reinforcement for abrasion
Low thermal conductivity and heat storage
Asbestos-free, chemical-resistant

Typical Applications

Hose, cable and conduit wrapping
Flange and manhole gasketing
Electrical and thermal barrier tapes
Expansion-joint edge protection

Installation & Handling

Wrap with a 50% overlap and secure the end with wire or high-temperature lacing. For live gaskets, compress lightly between flanges.

Standards & Compliance

Manufactured to ASTM C892, ASTM C1086, ISO 10635, EN 10964 and controlled under a documented quality system. Supplied by a manufacturer holding ISO 9001, CE and SGS certifications, exporting high-temperature insulation to 60+ countries since 1982.

Why Specify This Product

Combines stable high-temperature performance with straightforward on-site fabrication. The material is asbestos-free, chemically stable in neutral and oxidising atmospheres, and supplied with full technical data sheets to support specification and inspection. Supplied by a manufacturer holding ISO 9001, CE and SGS certifications, exporting high-temperature insulation to 60+ countries since 1982.

Manufacturer & Supplier

Rosetexwool is a ceramic fiber tape manufacturer and supplier serving more than 60 countries since 1982. Every ceramic fiber tape is produced under a documented quality system certified to ISO 9001, CE and SGS, with batch-level traceability from raw material to finished product.

What our manufacturing capability covers:

In-house melting, fibre-forming and finishing lines for consistent grade and density
Dimensional, density and thermal checks against ASTM C892, ASTM C1086, EN 10964
Asbestos-free, low-impurity formulations verified by incoming and outgoing inspection
Standard and custom sizes, OEM/ODM grades, and cut-to-size supply for project quantities

For quotations, lead times or technical data sheets, contact our team with your specification and target service temperature. Explore the ceramic fiber insulation hub for the full range, or read the ceramic fiber insulation buying guide for selection support.

Related Ceramic Fiber Products & Alternatives

custom ceramic fiber shapes — Lightweight and simple to install, custom forms remove the cutting waste and gap risk that come from trimming standard board to fit.

loose ceramic fiber insulation — The practical answer for irregular voids, penetrations and furnace expansion joints where a pre-formed product would need extensive cutting and still leave gaps.

rock wool acoustic panels — High-density stone wool panels tuned for a high noise reduction coefficient, giving thermal and acoustic performance from the same layer.

For the full ceramic fiber range, temperature grades and density options, see our ceramic fiber insulation guide.

For adjacent material options across temperature and application ranges, explore our rock wool insulation hub.

Part of the Ceramic Fiber product family.

Key features

✓ Flexible and easy to wrap
✓ Up to 1260℃ resistance
✓ Low thermal conductivity
✓ Good chemical stability
✓ Electric insulation
✓ Asbestos-free

Typical applications

Pipe and valve insulation
Cable fire protection
Expansion joint gasketing
Protective wrapping for hoses
Removable insulation covers

Technical specs

Thickness: 2/3/5mm
Width: 25-150mm
Temperature: Up to 1260℃
Reinforcement: Fiberglass filament
Asbestos: 100% Non-Asbestos

Last updated: September 19, 2026

Frequently asked

What temperature can ceramic fiber insulation withstand? +

Ceramic fiber insulation withstands temperatures from 1100°C to 1430°C, depending on the grade. Standard (ST) and High-Purity (HP) grades are rated for 1260°C, while High-Alumina (HA) handles 1360°C and Zirconia (HZ) reaches 1430°C. Always match the grade to your specific operating temperature.

What are the differences between COM, ST, HP, HA, and HZ grades? +

The grades differ mainly in alumina (Al₂O₃) content and temperature rating. COM (1100°C) is the economy grade. ST (1260°C) is the standard industrial grade. HP (1260°C) offers higher purity with lower shot content. HA (1360°C) has higher alumina for superior thermal stability. HZ (1430°C) contains zirconia for the highest temperature resistance.

Is ceramic fiber insulation safe? +

Yes. Our ceramic fiber products are 100% asbestos-free and manufactured to international safety standards. They are classified as non-carcinogenic under EU Directive 97/69/EC. We recommend standard PPE (gloves, dust mask) during handling, as with any fibrous insulation material.

How is ceramic fiber blanket installed? +

Ceramic fiber blanket can be cut to size with a utility knife and secured using high-temperature anchors, pins, or stud welding. For furnace linings, a layered installation is recommended. For pipe insulation, wrap and secure with stainless steel bands. Full installation guidance and technical support are provided with every order.

What are the typical applications for ceramic fiber products? +

Ceramic fiber is widely used in industrial furnaces, kilns, boilers, petrochemical heaters, power generation equipment, incinerators, and building fire protection systems. It is ideal for backup insulation, expansion joints, door seals, and high-temperature gaskets.
