Cryogenic Insulation

Cold stores, LNG transfer lines and liquid-nitrogen piping from −196°C, with closed-cell layers and a sealed vapour barrier.

Cryogenic and low-temperature applications need materials that stay effective far below ambient and resist moisture ingress. The priority is preventing condensation, heat leak and ice formation while keeping structures light. Hydrophobic rock wool serves cold rooms and chilled lines down to about -50 °C; calcium silicate provides a stable low-temperature envelope; glass wool fills acoustic and duct roles.

This page is the overview hub for cryogenic insulation, organised by service temperature band rather than by a single material. It sets out the standards, moisture-control rules and application scenarios shared by cold rooms, refrigerated transport and liquefied-gas systems. The detailed answers sit in four dedicated guides: the LNG tank and cryogenic vessel insulation guide for full-containment tanks and boil-off control, the cryogenic pipe insulation guide for transfer lines and thickness, the materials overview for low-temperature material behaviour, and the cold-storage and LNG applications article for project scenarios. Choose the temperature band here, then follow the matching guide for specification detail.

Material Comparison

MaterialBest fitService tempKey advantage
Rock wool (hydrophobic)Cold rooms, chilled lines, fire breaksdown to about -50 °CNon-combustible, economical, A1 fire class
Glass woolDucts, acoustic linings, chillersdown to about -20 °CLightweight, low cost, acoustic
Calcium silicateCold-storage walls, equipment, vehiclesdown to about -20 °CMoisture-proof, structural, stable

Application Scenarios

Cryogenic & Low-Temperature Application Scenarios

  • Cold-storage exterior walls — calcium silicate board resists low temperature and moisture.
  • Cold-chain logistics vehicles — calcium silicate keeps a stable low-temp envelope in transit.
  • Low-temperature laboratories — calcium silicate shields against external heat intrusion.
  • Cold-storage interiors — glass wool in chilled and frozen rooms.
  • Refrigerated equipment — glass wool in refrigerators, freezers and display cases.
  • Low-temperature pipe insulation — glass wool, and hydrophobic rock wool board, on refrigeration and liquid-nitrogen lines prevents heat leak.

Standards & Compliance

Cryogenic Insulation Standards

Low-temperature and cryogenic systems are governed less by a single material standard and more by the process safety codes that control flammable and liquefied gases, plus the moisture-control rules that decide whether an insulation system survives. The documents that matter most are the ones that govern LNG and cold containment.

  • NFPA 59A — the production, storage and handling standard for liquefied natural gas, which drives insulation and fire-protection choices around LNG tanks, regasification and process lines.
  • IMO IGC Code — the International Gas Carrier Code sets construction and insulation requirements for shipborne liquefied-gas carriers, including cargo containment and boil-off control.
  • EN 14303 — the European specification for factory-made mineral wool used in building equipment and industrial installations, covering product forms and declared properties for pipe and equipment insulation.
  • ASTM C552 — the specification for cellular glass (foam glass) insulation, a load-bearing, vapour-tight material widely used at LNG tank bases and cold supports.

Across all of them, the real design rule is moisture control: a continuous vapour barrier on the warm side, sealed laps and foamed penetrations decide whether the system lasts. The material is secondary to the detailing.

Material Selection Guide

How to Select Cryogenic Insulation

  1. Fix the temperature band and duty. Cold storage, cold chain and LNG each rule different materials in or out before conductivity is considered.
  2. Design the vapour barrier first. Place it on the warm side, make it continuous and seal every penetration; this is the single biggest determinant of service life.
  3. Choose the primary thermal resistance. Closed-cell foam and cellular glass for LNG and structural cold loads; mineral wool for cold rooms, chilled lines and fire breaks down to about -50 °C.
  4. Assign the secondary roles. Acoustic linings, duct insulation and fire separation are where glass wool and rock wool earn their place.
  5. Detail joints and supports. Cold bridges at supports, slabs and penetrations are where most cryogenic failures start.

See our rock wool board, glass wool blanket and calcium silicate board for the forms used in cold storage, chilled lines and low-temperature equipment.

Temperature Zone Material Map

Material Map by Service Temperature

Cryogenic and low-temperature service spans three very different bands, and the material that excels in one band is often wrong in another. The map below aligns our product families with the band they serve.

Service bandRepresentative serviceFirst-choice materialsWhy
−196 to −150 °CLiquid nitrogen, LNG, cryogenic propellant linesAerogel blanket, vacuum-supported systemsThermal conductivity stays flat and low as temperature drops; thin build-up on cramped pipe runs — see our nano aerogel insulation blanket
−120 to +400 °CChilled water, refrigerated transport, cold-store servicesGlass wool blanket and boardStable fibreglass structure across the whole band at low cost — our glass wool blanket covers duct, wall and pipe roles
−50 to +650 °CEquipment enclosures, dual-temperature offshore modulesRock wool board and blanketFire rating comes free (A1) where the cold side also needs hot-side protection — our rock wool board serves combined roles
Envelope and CUI protectionCold-store walls, tanks, pipe supportsCalcium silicate boardMoisture-tolerant and structural where vapour control is imperfect — our calcium silicate board is the default

For the engineering reasoning behind these pairings, our cryogenic insulation materials overview compares thermal conductivity curves, and our cold storage and LNG applications article maps them onto real projects.

Vapour Control & Boil-Off Design Notes

Vapour Control and Boil-Off: Where Cryogenic Systems Fail

Warm, humid air reaches every cold surface it can. When water vapour condenses and freezes inside an insulation layer it changes the layer's thermal conductivity by an order of magnitude, adds ice loads to supports, and eventually corrodes the pipe it was meant to protect. Three detailing rules decide whether a cryogenic system survives its first humid summer:

  • Sealed vapour barrier on the warm side — the membrane must wrap the entire cold volume, with laps glued and penetrations booted, not taped. A single unsealed lap pumps moisture into the layer for the life of the plant.
  • Interrupted thermal bridges — pipe supports, hangers and instrument tappings short-circuit the insulation. Load-bearing foam or insulated support blocks under every hard contact keep surface condensation off the structure.
  • Boil-off as the acceptance metric — LNG tank and pipe specifications are written in daily boil-off percentage, not conductivity. Every millimetre of missing insulation at a support or valve multiplies into measurable product loss, which is why thin aerogel build-ups on congested runs often beat thicker conventional layers.

Our cryogenic pipe insulation guide walks through the layer-by-layer build-up, and the piping applications page covers the ambient-temperature side of the same networks.

Closed-Cell & Load-Bearing

Cellular Glass, Foam and Load-Bearing Cold Insulation

Below about −50 °C mineral wool stops being the first choice, not because it cannot take the temperature but because the vapour problem becomes unsolvable. The materials that take over are closed-cell: cellular glass, polyisocyanurate and polyurethane foam.

Cellular glass (ASTM C552) is the structural option. It is vapour-tight by construction, does not burn, and carries compressive loads in the range of a megapascal, which is why it appears under tank bases, at cold supports and in load-bearing applications where foam would creep. Its weakness is that it is brittle and must be installed with bedding compounds at every joint.

PIR and PUR foam are the volume solution for pipe and panel work between roughly −196 and +120 °C, with thermal conductivity around 0.022 to 0.026 W/m·K. They are closed-cell but not vapour-proof in the way cellular glass is, so they live or die by the barrier around them.

Cold Room Construction

Cold Room Construction: Walls, Ceilings and Floors

A cold store is an insulated box built inside a building, and the box has three separate problems: the walls, the ceiling and the floor, each with a different structural duty.

Walls and ceilings are usually sandwich panels with a foam core, with panel joints sealed and the vapour barrier continuous on the warm face. The floor is where cold stores fail, because it carries forklift loading and is buried in the structure: it needs an insulated, load-bearing build-up with a heater mat or ventilation layer beneath to keep the ground from freezing and heaving.

Thermal bridges decide the rest. Steel columns passing through the envelope, door frames, drain pipes, and every penetration for a refrigeration line will condense or freeze unless it is broken with an insulated block or a structural thermal break. On a frozen store at −25 °C, a single unbroken steel column is enough to grow ice on the wall for the life of the building.

Cold Chain & Transport

Refrigerated Transport and the Cold Chain

Reefer containers, insulated truck bodies and rail cars carry the same physics in a much smaller, much more abused envelope. The insulation has to work while the box is loaded, washed, driven over rough ground and inspected between trips.

Panel cores are typically PIR or PUR between GRP or aluminium skins, with a target thermal transmission value for the body rather than a material specification — ATP-type acceptance tests the finished body, which is the right way round for transport. Floors need a reinforced core to take pallet truck point loads; doors need heated or insulated seals to stop the frame freezing shut.

Mineral wool is the wrong core here because of weight and moisture, but it remains the fire protection layer around the refrigeration unit and the fuel tank on many bodies, where its non-combustibility is worth more than its conductivity.

LNG Terminals

LNG Storage, Terminals and Loading Systems

LNG at −162 °C is the largest cryogenic duty in ordinary industrial service, and its insulation is written in boil-off rate rather than in thickness. A terminal is a chain of different insulation problems that must perform together.

Tank insulation is usually perlite in the annular space of a full-containment tank, or a membrane system with prefabricated panels on a carrier; the base is a load-bearing insulated deck that has to carry the product weight while limiting heat leak into the foundation. Pipe racks, loading arms and vapour return lines use foam or cellular glass with a factory-applied vapour barrier.

Every one of those elements is judged by the same number: how much product boils off per day. Insulation defects show up there first, long before they show up as visible ice.

Aerogel Retrofits

Aerogel for Thin-Profile Cryogenic Retrofits

Aerogel blanket occupies a specific niche: where the thermal performance is needed but the thickness is not available. Conductivity around 0.015 to 0.020 W/m·K at ambient, hydrophobic by nature, and flexible enough to wrap a valve or a congested manifold that no rigid section will follow.

In cryogenic work that usually means retrofits, skid-mounted equipment, and offshore or shipboard modules where every millimetre of build-up competes with walkway clearance. Three or four layers of aerogel with staggered joints and a sealed outer jacket can replace a much thicker conventional build-up in the same space.

The caveats are honest ones: cost per square metre is high, the material needs the same vapour barrier discipline as anything else, and compressive loads are not its job — at supports, cellular glass or a structural block still takes the weight.

Dew Point & Condensation

Dew Point, Surface Condensation and Anti-Sweat Design

On a chilled line the visible failure is on the outside: condensation forming on the jacket, then dripping, then staining and corroding whatever sits below. It is a psychrometric problem before it is an insulation problem.

The design condition is not the design day. At 30 °C and 70 per cent relative humidity the dew point is around 24 °C, so any surface below that temperature will wet. The jacket thickness is therefore chosen to keep the outer surface above dew point at the worst ambient condition the site will actually see, which on a cold store in a humid climate can govern the whole build-up.

Where the surface temperature cannot be held, the answer is mechanical rather than thermal: a sealed metal jacket with drainage, a drip tray, or a ventilated cavity. Painting a condensing surface never solves it for more than one season.

Commissioning & Inspection

Commissioning and In-Service Inspection of Cold Systems

A cryogenic system announces its defects physically: frost where there should be none, ice on a support, a cold patch on a jacket, a boil-off rate drifting upward. Reading those signs early is cheaper than any repair.

At commissioning the checks are continuity and dryness. The vapour barrier is inspected before the cladding goes on, because after that it cannot be verified; the insulation is confirmed dry, since trapped moisture will migrate to the cold face and stay there; and purge or dry-out of the annular space is completed before cooldown.

In service, thermography (ISO 18434-1 practice) finds wet or missing insulation as temperature anomalies, and a periodic boil-off or compressor-duty check catches the slow decline that visual inspection misses. Both are cheap compared with the energy a saturated layer costs every day.

Related Applications

Cryogenic service spans LNG, aerospace, and industrial gas. Related low-temperature and process applications:

Why Rosetexwool

Key Benefits

Why Cryogenic Insulation operations choose Rosetexwool insulation solutions.

Cold Retention

Low-temperature-stable boards and blankets maintain stable cold-chain and laboratory environments.

Moisture Resistance

Calcium silicate resists moisture and condensation at low temperatures, preventing degradation.

Energy Savings

Effective envelopes cut refrigeration loads and lower operating costs.

Long Service Life

Durable insulation reduces rework in cold storage and refrigerated transport.

Support

Frequently asked questions

What insulation is used for cold storage walls? +

Calcium silicate exterior boards (low-temperature and moisture resistant) plus glass wool interior layers for freezers and chillers.

Can you insulate cryogenic pipelines like liquid nitrogen? +

Yes. Glass wool and calcium silicate jackets protect low-temperature lines such as refrigeration and liquid-nitrogen piping from heat ingress.

Do you supply refrigerated transport insulation? +

Yes. Insulation layers for cold-chain vehicles and refrigerated equipment maintain stable low temperatures in transit.

What temperature can rock wool handle in cold service? +

Hydrophobic rock wool performs reliably down to about -50 °C when installed with a continuous vapour barrier and metal jacketing. That covers most cold rooms, chilled water and industrial cold ductwork. Below -50 °C, aerogel or cellular glass is the better primary choice; rock wool then appears only as an elastic buffer layer in tank construction.

What standards apply to LNG and cryogenic insulation? +

LNG facilities follow NFPA 59A and shipborne carriers follow the IMO IGC Code; mineral wool for industrial pipe and equipment is specified under EN 14303 and cellular glass under ASTM C552. In every case the governing rule is moisture control — a continuous warm-side vapour barrier decides whether the system survives.

Which insulation works at liquid nitrogen temperatures around −196 °C? +

Flexible aerogel blanket is the practical choice for liquid-nitrogen and LNG service: it keeps its thermal conductivity low and flat down to cryogenic temperatures, needs only a fraction of the thickness of fibrous materials, and its hydrophobic structure tolerates the imperfect vapour sealing found on real pipework. Glass wool serves the −120 to +400 °C band, while vacuum-insulated panels or perlite-filled annuli handle large flat tank faces where vibration is absent.

Why is the vapour barrier more critical than the insulation itself? +

Because cryogenic insulation fails from the outside in. If warm humid air reaches the cold surface, water vapour condenses and freezes inside the layer: thermal conductivity rises sharply, ice growth loads the structure, and cycle after cycle the system corrodes from beneath a intact-looking jacket. A continuous, sealed vapour barrier on the warm side — with glued laps, booted penetrations and insulated support blocks — is what preserves the performance the material was selected for.
