Traffic & Fire Protection

Tunnel linings, structural steel protection and cable shaft seals. Assemblies rated to EN 1366, ASTM E119 and the hydrocarbon curve.

Overview

Passive Fire Protection Is a Rated Assembly

Passive fire protection is bought as a rated assembly, not as a material. Whether the job is structural steel, a compartment wall, a ventilation duct or a cable tray, what an authority accepts is a tested system — board, density, fixing pattern and finish — that holds its rating for the stated period. The board on its own proves nothing.

What We Supply and How It Is Tested

Rosetexwool rock wool and ceramic fiber are Class A1 non-combustible, with melting points above 1,000°C. The assemblies we supply are tested against BS 476, EN 1366, ASTM E119 and EN 13381, so the rating quoted for a wall, a tunnel lining or a steel section is one the test report actually covers.

Material Options

Material Comparison for Fire-Rated Assemblies

Selecting fire-protection insulation for buildings, transport infrastructure and vehicles means balancing fire rating, service temperature and weight. How rock wool compares with the materials used across traffic and fire-protection projects:

MaterialService temperatureFire ratingThermal conductivityRelative costKey use
Rock wool-200 to 650°CA1 non-combustible0.032-0.040 W/(m·K)LowCurtain-wall fire stopping, fire barriers
Ceramic fiberup to 1260°CA1~0.03HigherHigh-temp tunnel & furnace linings
Calcium silicateup to 1100°CA1~0.05-0.06MediumRigid boards, damp areas
Glass woolup to 400°CA1~0.03-0.04LowLightweight acoustic & fire linings
PIR / PU foam-50 to 150°CB-s1,d0 (PIR) / B2 (PU)0.022-0.027MediumThermal-only; needs fire barriers

For most traffic and fire-protection assemblies rock wool delivers the best balance: A1 non-combustible, mechanically strong and cost-effective, while ceramic fiber handles extreme temperatures in tunnel and furnace zones.

Application Scenarios

Facades, Compartments and Structural Steel

Building work is governed by the test standard rather than by temperature: A1 non-combustibility, and geometry that survives a cellulosic fire curve without shrinking away from the gap it is supposed to seal.

  • Curtain-wall fire stopping — rock wool slabs fill the cavity between floor slabs and the facade, forming a fire and smoke barrier at every floor line (tested to EN 1364 / ASTM E2307).
  • External wall insulation fire barriers — non-combustible rock wool break strips interrupt combustible EIFS layers on high-rise facades.
  • Steel-structure fireproof encapsulation — rock wool boards clad exposed steel beams and columns, preserving load capacity during a fire.

Tunnels and Rail Interiors

Transport infrastructure adds a confined space, an evacuation problem, and — for rail vehicles — a harmonised European requirement layered on top of the building codes.

  • Tunnel lining & escape-route protection — ceramic fiber and rock wool boards line tunnel crowns and evacuation corridors, protecting escape paths.
  • Rail & rolling-stock interiors — rock wool and glass wool meet EN 45545 fire-safety requirements for train ceilings, walls and underfloor insulation.

Vehicles, Batteries and Adjacent Sectors

The same materials carry into mobile equipment, where the fire starts inside the asset instead of beside it. Marine and battery work is covered in more depth on the linked pages.

  • EV battery-pack thermal runaway protection — rock wool fire layers and calcium-silicate nano super-insulation boards sit between cells and modules. The nano board meets UL 2580, sized for the 1,000°C-plus vent plume of a failing cell and giving 2-hour no-ignition protection at ~0.03 W/(m·K).
  • Energy-storage system safety — calcium-silicate boards block thermal propagation from a failing battery cell to other units in storage cabinets.
  • Turbocharger & exhaust heat shields — ceramic fiber shields wrap turbochargers and heavy-machinery exhausts (to 1200°C), keeping surface temperatures within touch-safe limits around hot machinery.
  • Marine fire divisions & A-60 bulkheads — rock wool and calcium silicate are the standard SOLAS materials for A-60 decks and divisions; the full compartment build-up is set out in our marine & offshore guide.

Material Choice Follows the Hazard

Material choice follows the hazard: for facade and compartment fire stopping rock wool is preferred for its rigidity and A1 rating; for high-temperature tunnel, exhaust and turbocharger zones ceramic fiber is specified (to 1200°C); in humid, salt-spray marine areas calcium silicate adds moisture and corrosion stability, and its nano super-insulation board is the go-to for EV-battery and energy-storage fire safety. Rosetexwool supplies cut-to-size boards, slabs, blankets and jackets with the required fire-certificate documentation for each project.

Tunnel Fire Performance

Tunnel Fires: What the Lining Actually Has to Do

Tunnel fires are among the most punishing thermal events an insulation system can face. A design fire of tens of megawatts develops inside a confined bore, the concrete lining is spalled by rapid thermal shock, and the steel reinforcement in the crown loses strength within minutes. In a tunnel, insulation is not a comfort or efficiency item — it is what keeps the structure standing and the escape route passable long enough for people to get out.

Concrete linings are already non-combustible, so the question is not flame spread but thermal protection of the structure and of the services running alongside it. Three material families cover that duty inside one bore:

  • Crown and high-heat zones — ceramic fiber board and blanket, rated for continuous service far above any fire-time gas temperature, used as the hot-face layer behind a protective facing.
  • Escape galleries, cross-passages and cable ducts — rock wool board at 100–180 kg/m³, A1 non-combustible under EN 13501-1, holding geometry and thermal performance through repeated wet/dry cycling and traffic vibration.
  • Wet or seeping sections — calcium silicate board, dimensionally stable where water runs down the bore instead of being absorbed and degrading the layer.

Hydrocarbon Curves, Fixing and Handover

Where the bore carries hazardous-goods traffic or sits close to petrochemical plant, the design fire follows the hydrocarbon (HC) heating curve rather than the standard building curve — a far higher peak and rate of rise. Size the hot-face layer for that curve. Do not size it from a standard fire test and assume the margin holds.

Fixing matters as much as material choice. Tunnel boards are anchored to the concrete with welded pins or drive-in anchors carrying washers, fitted with compression so the board stays in contact under traffic vibration and any pressure wave. Board joints are closed, and the layer is protected against water ingress before the final rendering, paint or facing is applied.

Every tunnel package ships with EN 13501-1 classification reports, non-combustibility test data and fixing details for the lining profile you supply. For the background behind A1 ratings and non-combustible systems, see non-combustible insulation systems and A1 fire ratings.

From Rating to Millimetres

From Rating to Millimetres: Section Factor First

Every steel fire-protection job starts with the same question, and the honest answer is more nuanced than a rule of thumb: how thick does the board have to be? For fibre boards such as rock wool and ceramic fiber the governing behaviour is thermally thick — once the layer is deep enough that its cold face no longer reaches thermal equilibrium during the test period, the fire resistance rating depends far more on the section factor of the steel (heated perimeter divided by cross-sectional area) and on the critical steel temperature you design to than on the conductivity of the board.

That is why the industry sizes protection from the rating tables built on EN 13381-4, the fire test method for load-bearing steel sections, read together with the thermal guidance in EN 1993-1-2 (Eurocode 3, design of steel structures exposed to fire). Those tables give the required thickness for R30, R60, R90 and R120 for a given section factor and critical temperature. In practice: set the critical steel temperature from the fire design calculation, read the thickness from the table, add the fixing and compression allowance, then verify the assembly for the exact profile rather than trusting the generic row.

Indicative ranges our engineers work from, before section factor and critical temperature are applied:

Required fire resistanceTypical board thicknessTypical densityCommon assembly
R30 / 30 minutes30–40 mm120–150 kg/m³Rock wool board, single layer, welded pins
R60 / 60 minutes40–60 mm120–180 kg/m³Rock wool board, single or two staggered layers
R90 / 90 minutes60–80 mm150–180 kg/m³Two layers, staggered joints, continuous pinning
R120 / 120 minutes80–100 mm150–200 kg/m³Two layers with wire mesh reinforcement, sealed external finish

Fixing, Penetrations and Access

Three details decide whether those numbers hold on site. First, fixing: pins must be long enough for the full compressed thickness, spacing is kept tight enough that no board bridges a void, and every pin carries a washer bearing on the board face. Second, joints and penetrations — a fire-rated wall or floor is only as good as the cables, ducts and conduits passing through it; those are closed with rated penetration seals and linear joint strips tested to the EN 1366 series, and the insulation is cut and fitted tight rather than left to fill a gap. Third, access for maintenance: valves, flange pairs and inspection hatches get removable panels built from rock wool board inside a wired mat, fastened with quick-release closures so the rating survives the tenth opening as well as the first.

Fire-rated assemblies also need a defined inspection path. Where the protection is buried in a ceiling, above a suspended grid or inside a cable duct, specify access panels at the intervals the maintenance plan requires — otherwise nobody learns that the board has settled until the next audit, or the next fire.

PFP Method Choice

Intumescent Coatings, Boards and Sprays: Choosing the Method

Structural steel can be protected three ways, and the right answer is decided by the section factor, the fire curve and the environment rather than by preference. Intumescent coating is thin, leaves the steel looking like painted steel, and works by swelling into a char when heated; boards and blankets are mechanical, robust and indifferent to the shape of the member; sprays are fast and cheap on large plain surfaces but cannot be detailed around a connection.

Section factor (the heated perimeter divided by the cross-sectional area) is the variable that sorts them. A heavy, compact section needs very little protection and a coating will do; a slender member exposed on all four sides needs a thickness of board that a coating cannot reach economically. Where the fire curve is hydrocarbon rather than cellulosic, coatings generally lose their advantage and mineral boards or cementitious sprays take over.

The site conditions decide the rest. Coatings need a controlled application environment and a dry, cured film; boards survive being knocked by scaffolding and can be replaced locally; sprays are impossible to match visually after a repair. On exposed structural steel in a car park or a station concourse, the robustness of a board often outweighs a small cost advantage elsewhere.

Related Applications

Fire-safe transport and infrastructure require certified non-combustible insulation. Related safety and building applications:

Related guides: fire rating comparison.

Why Rosetexwool

Key Benefits

Why Traffic & Fire Protection operations choose Rosetexwool insulation solutions.

Certified Fire Performance

Products tested to international standards — CE-marked rock wool with Euroclass A1 reaction to fire classification.

No Smoke or Droplets

Rock wool and ceramic fiber produce no smoke and no burning droplets when exposed to fire — critical for safe evacuation.

Compartment Integrity

Properly installed fire stopping maintains the fire-resistance of rated walls and floors, preventing fire spread.

Asset Protection

Fire-rated cable tray protection keeps critical circuits operational during a fire for safe shutdown and emergency response.

Support

Frequently asked questions

What fire rating can rock wool board achieve? +

Depending on thickness and installation method, rock wool board systems can provide 30 minutes to 4 hours of fire protection for structural steel, as tested to BS 476 Part 21 or EN 13381-8. We recommend consulting local fire engineering codes for required thickness.

Is ceramic fiber acceptable for building fire protection? +

Ceramic fiber is primarily used in industrial and high-temperature fire protection applications. For general building fire protection, rock wool is more commonly specified due to its bio-solubility and broader regulatory acceptance. We can advise on the most appropriate product for your application and jurisdiction.

Do you provide fire-rated duct insulation systems? +

Yes. We supply rock wool board and blanket systems for both horizontal and vertical fire-rated ventilation ducts tested to EN 1366-1 and BS 476 Part 24. Contact us with your duct dimensions and required fire rating period.

How thick should rock wool be for a 60-minute or 120-minute fire rating? +

It depends on the section factor of the steel and the critical temperature you design to, not on the conductivity of the board alone. Fibre boards behave as thermally thick layers, so the rating tables built on EN 13381-4 for load-bearing steel sections give the required thickness for R30, R60, R90 and R120. As an indicative working range: 30–40 mm for 30 minutes, 40–60 mm for 60 minutes, 60–80 mm for 90 minutes and 80–100 mm for 120 minutes, at densities from 120 up to 200 kg/m³ for the longer ratings. Always confirm against a test or assessment for your actual profile, and add the fixing and compression allowance.

Do tunnel linings need fire protection insulation, or is the concrete enough? +

For reaction to fire the concrete lining is already non-combustible, so no combustible layer is needed. Insulation is still specified for two other reasons: it limits thermal shock spalling of the concrete and the softening of the steel reinforcement in the crown, and it keeps escape galleries, cross-passages and cable ducts cool enough to remain usable. High-heat crown zones take a ceramic fiber hot-face layer, escape routes and cable ducts take A1 rock wool board, and seeping sections take calcium silicate because it stays dimensionally stable in wet conditions.

Can passive fire protection be inspected or replaced after it is opened for maintenance? +

Yes, when the assembly was designed for it. Fittings, valves and inspection hatches should be fitted with removable panels: a wired rock wool mat inside a cover with quick-release fasteners, overlapping the fixed insulation by at least 50 mm so the seal is never broken at the joint. Re-refitting correctly restores the fire rating; re-opening a bonded or rigidly bonded board without restoring the original fixings and joint sealing does not. Plan inspection access at the intervals your maintenance regime needs, especially where the protection sits behind a suspended ceiling or inside a cable duct.
