Aerospace & Defense

Cargo fire barriers, engine firewall blankets and re-entry protection, qualified on backface temperature rather than a datasheet limit.

Three Regimes: Orbit, Airframe and Propulsion

Aerospace and defense impose the most demanding insulation requirements in industry: extreme heat resistance combined with lightweight construction, high reliability and long service life. Cabin and cargo fire barriers must be non-combustible yet light; launch and re-entry systems need materials that survive instantaneous ultra-high temperatures; structural partitions must keep their strength under thermal and mechanical load.

What We Supply for Flight Hardware

Four material families cover the work on this page. Rock wool handles cargo fire barriers and hangar structures to 650 °C; glass wool gives the lowest weight for cabin and compartment thermal control; ceramic fiber in blanket, paper and textile form carries engines, nozzles and re-entry surfaces from 800 °C upward; and calcium silicate board supplies the compressive strength that fire partitions and bulkheads need.

Material Comparison

Material Map for Aerospace and Defense

The table sets the four families against each other on the two criteria that decide aerospace procurement: the temperature band each one covers, and the structural role it can still play once installed.

MaterialBest fitService tempKey advantage
Rock woolCargo fire barriers, hangarsup to 650°CNon-combustible, structural fire
Glass woolCabin & compartment insulationup to 400°CLightweight, thermal comfort
Ceramic fiberEngines, rockets, spacecraftup to 1260°C continuousUltra-high-temp, low mass
Calcium silicateFire partitions, bulkheads600–1000 °CHigh-strength fire structure

Temperature Bands

The Same Airframe Spans 1,400 Degrees

A single vehicle can carry liquid oxygen at -183 °C in one bay and a nozzle throat above 1,000 °C a few metres away. No one fibre covers that, so we specify by band instead of by material loyalty:

BandTypical hardwareWhat we specify
-253 to -150 °CLiquid-hydrogen and LOX tanks, transfer lines, cold platesAerogel blanket behind a sealed vapour barrier, with closed-cell support on curved surfaces
-60 to 150 °CCabin walls, avionics bays, equipment racksGlass wool or thin aerogel, encapsulated for fibre containment
150 to 650 °CAPU bays, bleed-air lines, engine accessoriesRock wool blanket or calcium silicate board behind a stainless shield
650 to 1260 °CNozzles, re-entry surfaces, hypersonic leading edgesCeramic fiber blanket, paper and textile

The bands overlap in a real assembly, and the joint between two of them is where designs usually fail: a stainless shield sitting at 600 °C bolted to an aluminium frame conducts heat straight past a metre of perfectly good insulation. We detail the transition as carefully as the field.

Application Scenarios

Airframe, Cabin and Cargo

Cabin, cargo and divider work is a mass problem before it is a temperature problem; each of these assemblies is qualified on burn-through time at minimum weight.

  • Aircraft cargo fire barriers — rock wool layers stop cargo-zone fires from reaching the cabin.
  • Aircraft cabin insulation — glass wool regulates cabin temperature with minimal weight.
  • Aircraft fire partitions & ship bulkheads — calcium silicate boards provide high-strength, non-combustible dividers.

Propulsion and Re-entry

Propulsion and re-entry assemblies see the opposite duty: short, extreme heat flux, where fibre purity and the part's own thermal mass decide whether it survives.

  • Rocket engine insulation — ceramic fiber shields engine components against instantaneous ultra-high temperatures.
  • Landing gear & engine heat shields — ceramic fiber blankets protect airframes during high-heat operation.
  • Spacecraft re-entry blankets & suit liners — multi-layer ceramic fiber composites protect vehicles and crew during re-entry and EVA.
  • Reusable launch vehicle fuel-tank insulation — ceramic fiber textiles stabilize propellant temperatures.
  • Hypersonic vehicle thermal seals — woven spring-ceramic fiber seals rated to around 900°C for crewed and experimental vehicles.

Sizing

Thickness Is a Mass Budget Decision

On a building you insulate to a U-value. On an aircraft or a launch vehicle you insulate to a backface temperature, and the thickness that gets you there is whatever mass the programme will tolerate. Two limits usually govern: roughly 120 °C for epoxy composite structure and roughly 150 °C for aluminium — both far below the surface the insulation is protecting.

Under steady heat flux backface temperature falls close to linearly with thickness, until the blanket's own conductivity starts to climb at temperature. In practice the trade sits between 12 and 50 mm: 12–25 mm of ceramic fiber blanket covers most engine-bay and APU shielding, and 25–50 mm is used where soak-back or a long dwell time drives the calculation. Where the envelope will not accept that depth, aerogel blanket reaches a similar backface in roughly a third of the thickness at 0.013–0.018 W/(m·K).

Two corrections get forgotten. Compression at clamps and fasteners removes effective thickness faster than most designers expect. And at altitude the thinner air reduces convective loss from the cold face, which changes the answer for cabin and avionics insulation but not for a radiatively heated shield.

Certification

Certification, Traceability and What the Buyer Actually Needs

Choosing the material is the easy half. The other half is proving it behaves in the assembly the way it behaved in the test, batch after batch.

  • Cabin interiors — 14 CFR 25.853 vertical burn, heat release and smoke density for anything inside the pressure vessel, applied to the facing and the adhesive as well as the fibre.
  • Cargo compartments — 14 CFR 25.855 liner and barrier requirements, where rock wool is normally the non-combustible core.
  • Hangars and ground facilities — ASTM E84 surface burning and EN 13501-1 A1 classification for the building envelope.
  • OEM limits — Boeing and Airbus smoke and toxicity requirements applied to the finished blanket, which is why encapsulated rather than bare fibre is so often specified.
  • Paperwork — batch traceability, certificate of conformity, REACH and RoHS declarations, and an asbestos-free statement, in the form AS9100-series supplier audits expect to see.

Every lot ships with fibre chemistry, nominal and tolerance thickness, density and the relevant burn or non-combustibility report, referenced to the batch number on the label.

Installation

Encapsulation, Fastening and Vibration

Bare fibre does not survive an airframe. What we supply for flight hardware is either encapsulated in glass cloth, silicone-coated cloth or foil, or delivered as paper and textile for the customer to laminate. Encapsulation keeps fibre out of occupied spaces, keeps fuel and hydraulic fluid out of the blanket, and gives the assembly something to fasten through.

  • Stitch pitch — 100 to 150 mm in both directions stops the blanket sagging between supports under vibration.
  • Fasteners — studs and washers set at least 25 mm in from the edge, with a compression washer that spreads the load without flattening the blanket.
  • Expansion — hot sections move; the blanket and its jacket need a slip joint or an oversize hole, or the first thermal cycle tears the facing.
  • Moisture — cryogenic assemblies are sealed and purged before close-out; a blanket closed over a damp surface ices at the cold face.
  • Inspection — thickness and density on a sampling basis, plus a visual for voids at brackets and penetrations, which is where backface temperature is actually exceeded.

Cost & Value

Where Ceramic Fiber Earns Its Cost

Ceramic fiber costs several times what rock wool does, so it is specified only where the temperature band or the mass budget rules rock wool out. Below 600 °C rock wool or calcium silicate usually does the same job at lower cost and with better structural behaviour; above 800 °C, and anywhere the assembly is qualified on mass, ceramic fiber textile and blanket are the practical answer.

Engine Fire Zones

Engine Fire Zones and Firewall Insulation

The engine nacelle is the one place in a civil aircraft where insulation is a certified fire barrier rather than a thermal product. FAR/CS 25.1191 requires a firewall between a designated fire zone and the rest of the aircraft, capable of resisting a 1,093 °C flame for 15 minutes without allowing the fire through.

In practice that means a fireproof blanket or a fireproof reinforced silicone/glass laminate on the engine side, sealed at every penetration. The seals are the certified part: a firewall with a hose or a control cable passing through an unsealed grommet has no rating at all, however good the blanket is.

Weight sets the design pressure on the rest of the nacelle. Acoustic and thermal blankets inside the cowl perform three jobs at once — attenuating fan noise, keeping the cowl surface cool enough for the structure, and providing the fire barrier — which is why they are qualified as assemblies and not as materials.

Re-Entry TPS

Thermal Protection for Re-Entry and Hypersonic Vehicles

Above roughly 1,200 °C surface temperature the problem stops being insulation and becomes thermal protection. A re-entry or hypersonic vehicle heats by convection and radiation at the leading edges and nose, and the material has to survive that heat flux, the aerodynamic load on it, and the vibration of the structure underneath.

Three families are used. Ceramic fiber blanket and tile insulate low-flux areas and reusable surfaces; aerogel blanket sits behind them as a thin, low-conductivity backstop where the internal structure has a tight temperature limit; and ablative materials are used where the heat flux is high enough that sacrificing mass is cheaper than insulating against it.

What matters in specification is the backface temperature, not the material's classification limit. A blanket rated to 1,260 °C that lets the underlying structure reach 200 °C has failed its job just as surely as one that burns, which is why thickness is qualified against a thermal model and a test, not against a datasheet.

Aerospace and defense insulation must survive extreme heat, cold, and vibration. Related high-performance applications:

Beyond these applications, our engineering guides cover the three regimes where aerospace insulation is hardest: orbit, components and propulsion.

Why Rosetexwool

Key Benefits

Why Aerospace & Defense operations choose Rosetexwool insulation solutions.

Extreme Heat Protection

Ceramic fiber shields rocket engines, exhausts and landing gear from transient temperatures up to 1700°C.

Lightweight Reliability

Low-density fiber and composite structures meet stringent aerospace weight, reliability and service-life requirements.

Fuel & System Safety

Insulation on fuel tanks and electrical enclosures stabilizes temperatures and prevents thermal runaway.

Long Service Life

Durable, radiation-tolerant materials extend component life in demanding defense environments.

Fire Barrier Insulation

Aircraft cargo-hold and engine fire barrier insulation from A1 rock wool and calcium silicate partitions, plus ceramic fiber for hot zones up to 1700°C.

Radiation & Nuclear Spec

Radiation-tolerant, nuclear-spec thermal insulation for defense electronics and reactor-adjacent systems, combining thermal stability with radiation resistance.

Support

Frequently asked questions

What insulation is used for rocket engine components? +

Ceramic fiber blankets and boards with transient temperature resistance up to 1700°C, plus multilayer composites for re-entry thermal shields and suit liners.

Can you provide hypersonic thermal seals? +

Yes. Braided spring-ceramic fiber thermal seal assemblies (developed by space agencies) withstand around 900°C for spacecraft and X-series vehicles.

Do you supply aircraft fire barriers? +

Yes. Calcium silicate partitions between cabin and cockpit, and rock wool cargo-compartment fire layers, meet aviation fire-rating needs.

What is aerospace fire barrier insulation? +

It is the insulation that contains a fire within a designated zone on an aircraft or defense platform — typically A1 rock wool for cargo-hold liners, calcium silicate partitions for cabin boundaries, and ceramic fiber where temperatures reach 1700°C. It must be lightweight, non-combustible, and hold its shape under vibration.

What is aerospace nuclear insulation? +

Radiation-hardened thermal insulation specified for nuclear-powered vessels, reactor-adjacent systems, and rad-tolerant defense electronics. It combines thermal stability with low outgassing and radiation resistance, usually built from ceramic fiber or mica-based composites.
